Vibro Sifter (Vibro/Gyro Screen)

Vibro Sifter

Varahi Industries manufactures Vibro Sifters (also called Vibro/Gyro Screens) for efficient material separation and classification of dry powders or wet mediums. Using controlled mechanical vibration, these screens deliver reliable, high-throughput sieving in pharmaceuticals, chemicals, food processing, minerals, and more.

The machine generates horizontal, vertical, and circular vibrations. Feed enters the upper deck and is separated by particle size; fines pass through to lower decks while coarse fractions remain on top—enabling multi-deck classification.

Working Principle

Technical Specifications

Model Capacity (kg/hr) Motor Power (HP) Screen Diameter (mm) Screen Area (m²)
VVS-600 600 1 600 0.28
VVS-900 900 1 900 0.63
VVS-1200 1200 2 1200 1.13
VVS-1500 1500 2 1500 1.75

Capacities and specifications vary with material properties and operating conditions.

Key Features

  • Versatile screening for dry and wet mediums; solid–solid & solid–liquid separation
  • Efficient vibration mechanism for precise separation
  • Robust SS construction; hygienic & easy to clean
  • Adjustable eccentric weights to tune intensity & direction
  • Compact footprint suited to tight spaces

Applications

Pharmaceuticals

Sieving APIs & excipients

Food Processing

Spices, flours & ingredients

Chemicals & Agrochemicals

Powders & formulations

Minerals & Pigments

Fine particle classification
